Carbon Steel Pipe

Grade：Q195、Q215、Q235、A36、A106、A283etc
Design style: customizable
Delivery time: 7-10 days
Transportation: sea or land transportation
Minimum order quantity: 1 ton
Payment method: T/T, L/C, D/P,Western Union, etc.
Email: admin@zgcysteel.com
Whatsapp: +86-15194203913

WhatsappCONTACT US

Product Description

Spiral welded carbon steel pipe for hydraulic pipeline thick-wall SSAW steel pipe for piling and construction projects


Specification OD: 219-2032mm WT: 1.2-30mm
Technique SSAW (spiral submerged arc process)
Material API 5L / A53 GR BQ195 Q235 Q345S235 S355
Surface treatment External: 3PE, bitumen, epoxy powderInternal: Epoxy, bitumen, cement
NDT testing Hydrostatic testUT testRT test
End treatment Bevel

External 3PE Executive Standard DIN30670

DN Epoxy coating/um Adhesive coating/um Minimum thickness for PE coating(mm)
Common Enhanced
DN≤100 ≥120 ≥170 1.8 2.5
100 2.0 2.7
250 2.2 2.9
500≤DN<800 2.5 3.2
DN≥800 3.0 3.7

External Single-layer Epoxy Executive SY/T0315

Number Coating level Minimum thickness(um)
1 Normal level 300
2 Reinforce level 400

Internal FBE Executive SY/T0442

Pipeline operation requirements Internal coating thickness(um)
Drap reduction pipeline ≥50
Anti-corrosion pipeline Normal ≥250
Reinforce ≥350

Packing&Delivery

1).20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)

20 Feet Container:Load about 26 tons steel pipe, length under 5.8 meter.

2).40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)

40 Feet Container: Load about 26 tons steel pipe, length under 11.8 meter.

3).40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)

Bulk Vessel: Special length over 12meter, big quantity products, sea freight is cheap.

4) Lead Time: within 10-25 workdays normally
5) Packing: Standard seaworthy packing or as per your request .(as pictures)

Products Show
